ceiling recessed luminaire DOWNLIGHT P 230 DALI rigid, DALI controllable, impact resistant, wired through IP54, white dimmable

LED Recessed Ceiling Light DOWNLIGHT P 230 40 HG 840 60 ML DALI WH

The LED Recessed Ceiling Light DOWNLIGHT P 230 40 HG 840 60 ML DALI WH is a high-quality recessed downlight lamp for professional indoor applications. With a diameter of 23 cm and a height of 9.45 cm, it is ideal for installation in cavity ceilings in dry indoor areas and wet rooms such as bathrooms, hallways, basements, sanitary rooms, or kitchens.

Technical Data

The ceiling recessed light has a power consumption of 29W and a luminous flux of 4030 - 5150lm. With an energy consumption of 29kWh/1,000 h and a light output of 183.18lm/W, it is energy efficient and saves electricity costs. The average lamp lifespan is an impressive 50,000 hours, ensuring long-lasting illumination.

Dimming and Control

This recessed ceiling light is dimmable and features a DALI switchable and continuously dimmable version, which is ideal for digital building automation systems. The power level or brightness can be set on the external LED driver, either at 6 watts or 8 watts, depending on the requirements.

Safety and Protection

With an IP protection rating of IP54 and an IK08 impact protection, this recessed light provides high protection against splash water, dust, vandalism, and accidents. The rear protection is IP20. The low glare effect with UGR 23 provides pleasant light without glare.

Other Features and Accessories

This recessed ceiling light comes with accessories such as DIP switches, driver, and external junction box. It provides neutral light output with a color temperature of 4000K and a color rendering index of 80Ra. The color consistency (MacAdam) is 3 SDCM, ensuring extremely low tolerance of color deviations. The light is available in different sizes and power levels, with a glossy silver or matte white inner ring.
