LED 3-Phase luminaire NUMINOS PHASE M, 3000K, 60°, 1880lm, black/black

SLV




LED 3-phase spotlight NUMINOS PHASE M, 230V / 500mA, CRi >90, dimmable

The LED 3-phase spotlight NUMINOS PHASE M is a high-quality product for 3-phase high-voltage track systems. With an operating voltage of 230V and a constant current of 500mA, it offers high energy efficiency and a power consumption of 20.1W. Thanks to its dimmable function and a rotation range of 350°, it is versatile and provides pleasant lighting.

Various combination options

In the NUMINOS series, various combination options are available, including track spotlights, recessed and surface-mounted lights, as well as pendant lights. This allows you to customize your lighting concept and integrate the LED 3-phase spotlight optimally into your space.

Durable and maintenance-free

The LED 3-phase spotlight NUMINOS PHASE M impresses not only with its high energy efficiency, but also with its durable and maintenance-free construction. With an average lamp lifespan of 50000 hours, you can enjoy long-lasting lighting without having to worry about regular maintenance.

Excellent color rendering and low glare

With a color rendering index of over 90 Ra, the LED 3-phase spotlight NUMINOS PHASE M provides excellent color rendering. The low glare effect (UGR <22) also ensures pleasant lighting without disturbing glare effects. With a warm white light color and a luminous flux of 1880lm, the spotlight creates a cozy atmosphere in your space.

Easy installation and flexible adjustment

The LED 3-phase spotlight NUMINOS PHASE M can be easily integrated into a track system and offers the option to replace the pre-installed black decorative ring with an optional white trim ring. With an IP protection rating of IP20 and a weight of 0.814kg, the spotlight is easy to handle and can be flexibly adjusted to your needs.

Article number:
1004180
Purchasing quantity:
1 piece
Brand:
SLV
Energy efficiency category:
E
EPREL No:
791822
Product type:
3-phase spot
Energy consumption:
21 kWh/1.000 h
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
trailing edge, TRIAC
Constant current:
500 mA
Lamp shape:
round
Power frequency:
50/60 Hz
Power consumption:
20,1 W
Emitting angle:
60 °
Bulbs in delivery:
yes
LED can be replaced :
replaceable by a specialist
Bulb type:
LED
Voltage:
3-phase adapter
Light colour:
warm white
Light emission:
direct
Light flux:
1880 lm
Light yield:
94 lm/W
Nominal current:
500 mA
Colour temperature:
3000 K
Average life span of a bulb in hours:
50000 Std.
Colour rendering index:
90.00 Ra
UGR:
< 22
Colour rendering index:
1A
lamp performance:
20 W
Colour:
black
Material:
aluminium

plastic
Turning range:
350 °
Dimension:
visible part-Ø∕ L∕ H: 8,5∕ 18,5∕ 16,5 cm
Weight:
0,814 kg
Plug type:
adaptor
Mounting:
track based mounting
Field of application:
ceiling

wall
Protection class:
1
IP-protection class:
IP20
Application area:
only suitable for indoor use
Additional information:
System power: 28W
Accessories:
decorative ring incl

driver incl

3-phase adapter incl

3-phase track excl
ambient temperature:
-20 ... +30 °C
