LED 3-phase spot NUMINOS® ZOOM M PHASE, 20W, 4000K, 15°, white

SLV




3-Phase LED Spotlight NUMINOS® ZOOM M

The 3-Phase LED Spotlight NUMINOS® ZOOM M is a high-quality spotlight specifically designed for 3-phase high-voltage track systems. With a power consumption of 20W and a luminous flux of 780 - 1900lm, it provides bright and uniform illumination.

Individually Adjustable Beam Angle

A special feature of the NUMINOS® ZOOM M is the adjustable beam angle, which can be varied directly on the spotlight between 15° and 60°. This allows the light to be directed precisely and tailored to the specific needs.

Various Applications

Thanks to its high color rendering index of over 90Ra, the spotlight is ideal for use in various areas such as ceilings and walls. With a protection class of 1 and an IP protection rating of IP20, it is suitable for indoor use only.

Easy Installation and Dimmability

The NUMINOS® ZOOM M comes with a 3-phase adapter, making it easy to install. The LED driver is already installed, and the spotlight is dimmable with a classic phase-cut dimmer to adjust the light intensity individually.

Variant Selection and High Energy Efficiency

The NUMINOS® ZOOM M is available in three different light colors and two housing colors. With an energy efficiency class of E and an energy consumption of 20kWh/1,000h, the spotlight is also environmentally friendly and energy-efficient.

Article number:
1006113
Purchasing quantity:
1 piece
Brand:
SLV
Energy efficiency category:
E
EPREL No:
791825
Product type:
3-phase spot
Energy consumption:
20 kWh/1.000 h
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
trailing edge
Constant current:
500 mA
Lamp shape:
round
Power frequency:
50/60 Hz
Power consumption:
20 W
Emitting angle:
15-60 °
Bulbs in delivery:
yes
LED can be replaced :
replaceable by a specialist
Bulb type:
LED
Voltage:
3-phase adapter
Light colour:
neutral white
Light emission:
direct
Light flux:
780 - 1900 lm
Nominal current:
500 mA
Colour temperature:
4000 K
Colour rendering index:
90.00 Ra
UGR:
< 25
Colour rendering index:
1A
Colour:
white
Material:
aluminium

polycarbonate (PC)
Turning range:
350 °
Dimension:
visible part-Ø∕ L∕ H: 8,5∕ 19∕ 16,5 cm
Weight:
0,989 kg
Plug type:
adaptor
Mounting:
track based mounting
Field of application:
ceiling

wall
Protection class:
1
IP-protection class:
IP20
Application area:
only suitable for indoor use
Additional information:
System power: 28W
Accessories:
3-phase track excl

3-phase adapter incl

driver incl
