LED CRI9R Linear 48V-Flex strip, 8W, IP68, red, 30 meter

ISOLED



We use Trusted Shops as an independent service provider for obtaining reviews. Trusted Shops has taken measures to ensure that the reviews are genuine.
More information
Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

High-Quality LED Strip with Outstanding Color Rendering

The AQUA CRI9B LINEAR 48V Flexband LED Strip from ISOLED impresses with its first-class color rendering, featuring a CRI value of over 95Ra, which makes colors appear especially natural and vivid. The fixed red light color provides intense and uniform illumination. With 240 LEDs per meter and a luminous flux of 1100 lumens per meter, this LED strip delivers brilliant lighting that adds a special atmosphere to any project.

Robust and Durable Construction with IP68 Protection Rating

This fully silicone-coated LED strip is equipped with an IP68 protection rating, meaning it is completely waterproof and can even be submerged permanently. The transparent silicone tube housing is UV-stable and reliably protects the LEDs from moisture and dust. The average lifespan of up to 70,000 hours guarantees long and low-maintenance use, while the high switching endurance of 100,000 switching cycles ensures stable performance.

Easy Installation Thanks to Comprehensive Accessories

The LED strip comes with all essential mounting aids: connection cables, end caps, adhesive, mounting brackets, and a silicone tube are included in the delivery. The back is self-adhesive with a high-quality 3M 300LSE adhesive tape, making attachment particularly simple. The connection method is soldering, and thanks to pre-installed connection cables on both sides, the strip can be conveniently powered and connected in various positions.

Efficient Technology with 48V Operating Voltage

The LED strip operates at a 48V DC operating voltage, allowing longer supply lines with lower voltage losses and reduced current flow. This enables power feeds up to 20 meters in length without compromising light quality. The power consumption is 8 watts per meter, which, combined with a luminous efficacy of 90 lumens per watt, provides efficient illumination. The flexible design with a minimum bending radius of 5 cm makes adaptation to various applications especially comfortable.

Versatile Applications and Flexible Adjustment

The LED strip is available in various lengths as well as with different light colors and power levels, allowing optimal adaptation to individual needs. Each segment can be cut every 5 cm, enabling precise length adjustments. Dimming is done via PWM (pulse-width modulation), allowing stepless control of light intensity. This product is ideal for anyone seeking a durable, powerful, and professional LED lighting solution.

Colour:
white
Glass color:
transparent
Dimension:
L∕ W∕ H: 3000∕ 1,2∕ 0,6 cm
min. bending diameter-Ø: 5 cm
individual sections-L: 5 cm
LED distance-Ø: 0,42 cm
Material:
plastic
copper
silicone
Weight:
1 kg
Product type:
fully siliconised LED strip
Accessories:
connection cable - included in delivery
end caps - included in delivery
adhesive - included in delivery
mounting bracket - included in delivery
silicone tube - included in delivery
dimmer - not included in delivery
profile - not included in delivery
driver - not included in delivery
Operating voltage:
48 V=
Dimmable:
yes
Dimmability:
PWM dimming
Power consumption:
240 W
Power consumption per meter:
8
Emitting angle:
120 °
Light colour:
red
Beam direction:
symmetriccal
Light flux:
21600 lm
Luminous flux per metre:
720
Light yield:
90 lm/W
Average life span of a bulb in hours:
70000 Std.
Switching cycles:
100000
Colour rendering index:
95 Ra
1A
Maximum operable length:
3000
Protection class:
3
IP-protection class:
IP68
Additional information:
Transformer power: 21 VA
ambient temperature:
-20 ... +45 °C
Energy efficiency category:
F
EPREL No:
820312
Energy consumption:
240 kWh/1.000 h
Article number:
ISO-114238
Purchasing quantity:
1 piece
Brand:
ISOLED
Manufacturer:
ISOLED
Manufacturer information
ISOLED FIAI Handels GmbH, Egerbach 48, 6334, Schwoich, Austria, product-details-service@isoled.shop, www.isoled.shop/details
