LED Mono Spot for object lighting, seamless height up to 30cm, 24V DC, CRi>90, rotatable, swiveling, 1.5W 3000K 38°, alu

Hera




LED MONO SPOT for object lighting

The LED MONO SPOT is perfect for object lighting in close range. With a continuously adjustable height of up to 30 cm and a rotatable and tiltable design, objects can be optimally showcased. The optic features a focus lens for precise light distribution.

Technical Details

The LED MONO SPOT has an operating voltage of 24V DC and an energy consumption of 2kWh/1,000h. The color rendering index is over 90Ra, ensuring very good color reproduction. With a power consumption of 1.5W and a luminous flux of 80lm, the spot produces a pleasant warm white light color.

Design and Material

The LED MONO SPOT has a round design made of aluminum and plastic. With dimensions of 3.2 x 3.2 x 30 cm and a weight of only 0.15 kg, the luminaire is lightweight and inconspicuous. The installation is done through surface mounting and the connection cable is 220 cm long.

Dimmability and Application

The LED MONO SPOT is dimmable with the appropriate accessories. It has a 360° rotation range and is perfect for use in furniture. The spot is suitable for indoor use only and has an IP protection rating of IP20.

Additional Information

The LED MONO SPOT is not only energy efficient with a light output of 53lm/W, but also durable with an average lamp lifespan of 60,000 hours. The luminaire is height-adjustable and has very good color reproduction for the perfect staging of objects. With the LED-24 plug system, the connection is simple and secure.

Article number:
HE-20202780102
Purchasing quantity:
1 piece
Brand:
Hera
Energy efficiency category:
G
EPREL No:
932822
Product type:
object luminaire
Energy consumption:
2 kWh/1.000 h
Manufacturer:
Hera
Operating voltage:
24 V=
Dimmable:
yes
Dimmability:
with optional features only
Lamp shape:
round
Power consumption:
1,5 W
Bulbs in delivery:
yes
LED can be replaced :
no
Bulb type:
fixed LED (non interchangeable)
Light colour:
warm white
Light emission:
symmetric
Light flux:
80 lm
Light yield:
53 lm/W
Colour temperature:
3000 K
Average life span of a bulb in hours:
60000 Std.
Colour rendering index:
90-100 Ra

1A
Colour:
aluminum matt
Material:
plastic

aluminium
Turning range:
360 °
Fitting opening circle :
1,5 cm
Dimension:
tube-Ø: 1,05 cm

material thickness-H: 2 cm

luminaire foor-Ø∕ H: 3,2∕ 0,9 cm

spot-Ø∕ L: 1,5∕ 3,2 cm

L∕ W∕ H: 3,2∕ 3,2∕ 30 cm
Weight:
0,15 kg
Length of connection lead:
220 cm
Plug type:
LED 24 plug-in system
Mounting:
surfaced mounting
Field of application:
furniture
Protection class:
3
IP-protection class:
IP20
Application area:
only suitable for indoor use
Additional information:
Transformer power: 21 VA
Accessories:
dimmer excl

connection cable incl

plug incl

controller excl

control gear excl
Luminaire is height-adjustable:
yes
ambient temperature:
-5 ... 35 °C
