Pluggable LED Stick LED Stick 2, without dark areas, 7cm, 8 LED, 0.8W 5000K 55°, CRi >80

Plug-in LED Stick LED Stick 2

The plug-in LED Stick LED Stick 2 from Hera provides uniform lighting without dark zones. With a length of 7 cm and 8 LEDs, it offers a high light output of 75lm/W. The color temperature is 5000K and the light color is cool white, ideal for use in furniture and on the wall.

Technical Details

The operating voltage of the LED stick is 24V= with a constant current of 34mA. The power consumption is 0.8W and the average lamp life is 60000 hours. The LED is not replaceable, but the light source is included in the delivery.

Material and Installation

The LED stick is made of aluminum and plastic and can be used for both recessed and surface mounting. The recessed opening has a rectangular shape with a length of 10 cm and a width of 1.2 cm. The stick is connected via the LED-24 plug system.

Additional Information

The LED stick has a wide beam angle of 40-80° and is suitable for light band configurations. It does not have a light distributor and is connected with through wiring. The operating device is voltage-controlled and meets the glow wire test according to IEC 60695-2-11 with 960 °C - 30 s.

Energy Efficiency and Certifications

The LED stick has an energy efficiency class G and a color rendering level of 1B with a color rendering index of 80-89Ra. The protection class is 3 and the IP protection rating is 20. With EPREL No. 874065, the LED stick complies with all required certifications and standards.
