recessed spotlight DIONE IP44 DIM 830 swivelling, wired through IP44, black dimmable
Deko-Light
421,97 DKK
excl. Shipping costs
Shipping time: 3-5 days
Product no.: D-565395
EAN: 4042943176899
In stock: 688
High-Quality LED Recessed Spotlight DIONE IP44
The LED recessed spotlight DIONE from Deko-Light impresses with its high-quality workmanship and modern design in elegant black. With a diameter of 8.2 cm and an installation depth of only 3.9 cm, it fits perfectly into standard drill holes of 68 mm. The housing made of aluminum and plastic ensures robust and durable use. Installation is simple and secure thanks to the firmly installed spring clips and the tool-free quick-installation connection box with push-in terminals.
Efficient and Pleasant Lighting
The spotlight features a powerful COB LED with a power consumption of 8.5 watts and produces a luminous flux of 800 lumens at a warm white color temperature of 3000 Kelvin. The light is symmetrically distributed and provides pleasant general lighting with a beam angle of 36 degrees. Additionally, the LED module is pivotable by 30 degrees, allowing the light to be directed precisely. With a color rendering index of over 80Ra, colors are displayed naturally and vividly.
Technical Details and Energy Efficiency
The spotlight stands out due to its high energy efficiency with 94.12 lumens per watt and a low energy consumption of 9 kWh per 1,000 operating hours. The average lifespan is an impressive 50,000 hours, ensuring rare lamp replacements. The LED is firmly installed and cannot be replaced, simplifying maintenance. Protection class 2 and IP44 certification provide protection against splashing water, allowing the spotlight to operate reliably even in more humid environments.
Easy Installation and Versatile Connection Options
The installation of the DIONE recessed spotlight is carried out by recessed mounting in the ceiling. The connection box with quick-terminal and through-wiring enables fast and secure wiring without additional tools. The connection cable is 3x 20 cm long and features a terminal connection. Installation is compatible with conventional NYM cables 3x 1.5 mm². Furthermore, the spotlight is dimmable and supports phase-cut and phase-control dimmers, allowing flexible light control.
Accessories and Individual Customization Options
The scope of delivery includes, in addition to the spotlight, a connection box, spring clips, through-wiring, and the dimmable LED driver. For special requirements, optional accessories such as interchangeable reflectors with a 60° beam angle, frosted diffusion covers for soft area lighting, as well as safety distance holders and reducer rings are available. This allows the recessed spotlight to be optimally adapted to different installation situations and lighting needs. The color consistency is very low at 5 SDCM, which guarantees an even light image, especially when using multiple fixtures.
visible part-Ø∕ H: 8,2∕ 0,3 cm
driver-L∕ B∕ H: 6,6∕ 3,5∕ 2 cm
connection box-L∕ B∕ H: 7,5∕ 3,9∕ 2,3 cm
max. material thickness-H: 1,3 cm
plastic
clip springs - included in delivery
through wiring - included in delivery
driver - included in delivery
dimmer - not included in delivery
1B
Deko-Light Elektronik Vertriebs GmbH, Auf der Hub 2, 76307, Karlsbad, Germany, deko@deko-light.com
