track linear luminaire TRACK48 LINE+ 30CM DALI dimmable IP20, black matt dimmable

High-Quality LED Linear Light for the TRACK48 Rail System

The LED linear light from ISOLED with a length of 30 cm is specially designed for the low-voltage TRACK48 rail system. With a power of 10 watts and a color temperature of 3000K, it produces pleasantly warm white light that creates a cozy atmosphere. The luminaire features a matte black surface made of aluminum and plastic, which not only looks modern but is also robust and durable. Thanks to the compact dimensions of 30.4 x 2.2 x 4.3 cm, the light can be used flexibly in different environments.

Technically Advanced DALI DT6 Dimming Function

This LED linear light is equipped with a DALI DT6 interface, allowing switchable and dimmable control of the light intensity. The 4-pole system enables easy integration into modern building automation systems. The integrated through-wiring ensures a seamless connection of multiple luminaires, allowing larger areas to be evenly illuminated. The light operates at a safe operating voltage of 48 volts DC, enabling safe handling without special protective measures.

Optimal Light Quality and Energy Efficiency

With a luminous efficacy of 62 lumens per watt, the luminaire produces a luminous flux of 620 lumens while consuming only 10 kWh per 1000 hours. The color rendering is very high with a CRI value of over 90Ra, meaning colors are reproduced particularly naturally and brilliantly. A wide beam angle of 120 degrees ensures even and symmetrical light distribution, supported by the prismatic cover that diffuses the light and thus reduces glare.

Long Service Life and Easy Installation

The LED linear light impresses with a very long service life of up to 50,000 hours, significantly reducing maintenance costs and replacement intervals. The power factor of 0.95 also ensures efficient energy use. Installation is tool-free and flexible thanks to the integrated magnetic adapter, which allows quick mounting to the TRACK48 power rail. The scope of delivery includes the diffuser, through-wiring, and magnetic adapter, making installation straightforward.

Versatile Applications and Accessory Options

This linear light is part of the ISOLED TRACK48 system and can be combined with other luminaires available both as simple switch versions and as smart DALI variants. Although controllers, dimmers, power supplies, power rails, and drivers are not included in the scope of delivery, the system can be individually adapted to your own requirements through these accessories. Protection class 3 and IP20 protection rating ensure safe operation, while the color consistency SDCM3 guarantees a consistent light color across multiple luminaires.
